Datalogic Gryphon I GFS-4520 Fixed 2D Barcode Scanner USB

Brand: Datalogic | Model: GFS4520-BKK1-RED

Datalogic Gryphon I GFS-4520 Fixed 2D Barcode Scanner USB

normally $375 $299inc.
GST
Out of stock

Datalogic Gryphon I GFS-4520 Fixed 2D Barcode Scanner USB

Datalogic Gryphon I GFS-4520 Fixed 2D Barcode Scanner USB. This barcode scanner can scan from a mobile phone or LCD screen.

Gryphon I GFS4520, Kit, 2D, MP, Red illumination, 5V, USB-only, microUSB connector, Black (Kit includes Scanner and USB Cable 94A051968)

Main Features

  • Compact dimensions for easy installation
  • Wide angle 1 MP optics for superior scanning and Depth of Field
  • Advanced motion tolerance optics for first pass reading of any moving barcode
  • Automatic sensing, software, external, manual trigger options available
  • Datalogic distinctive red or white illumination technology with adjustable brightness
  • Intuitive Blue Dot LED aimer for easier targeted scanning
  • Superior good-read feedback (‘Green Spot’ technology, high visibility topfront LED and integrated beeper with adjustable intensity)
  • Omnidirectional reading of 1D, 2D and postal codes plus stacked, composite codes and dot codes; Digital Watermarks on red illumination models
  • Image capture and document scanning capabilities
  • USB, RS-232, USB/RS-232 communication options
  • Water and Particulate Sealing Rating: IP54
  • Disinfectant-Ready enclosure
  • EASEOFCARE Service Plans offer a wide range of service options to protect your investment, ensuring maximum productivity and ROI.

Discover the New Standard in Integrated Scanning Technology

Are you ready for an integrated scanning solution that combines ease of use, lightning-fast performance, and unmatched durability? Look no further than the Gryphon 4500 Fixed Series. With two versions available (with and without housing), and packed with value-added features and state-of-the-art architecture, this series of scan modules is designed to meet the demands of diverse industries and applications.

Compact Scan Modules for Seamless Integration

Say goodbye to complicated setups and hello to seamless integration. The all-new GFS4500 is a highly versatile compact scan module, ideal for scanning barcodes in kiosks and as an OEM barcode reader by machine manufacturers seeking to deliver efficient self-service capabilities. With its compact size and multiple fixing points, the GFS4500 scan module effortlessly fits into any enclosure. For more customized applications such as medical analysis machines or access control gates, the "naked" version GFE4500 offers enhanced flexibility. It is cutting edge technology in a space-saving design.

Achieve Unparalleled Reliability

When it comes to longevity, the Gryphon 4500 Fixed Series is built for endlessly scanning barcodes. Datalogic stands behind the quality of its products by offering a class-leading 5-year factory warranty. These compact scan modules are designed with durability in mind even in outdoor environments. With an IP54 sealing, resistance to knocks and drops and a UV-resistant output window, the GFS4500 scan module remains protected year-round, even through seasonal weather changes. This tough device ensures that operations run smoothly for years to come.

Experience Instantaneous Reading Performance

The Gryphon 4500 Fixed Series takes advantage of advanced megapixel technology with distinctive red or white illumination to guarantee continuous and reliable reading performance. Its fast internal processor combined with the sophisticated decoding algorithms makes reading any 1D or 2D barcode a breeze, even on mobile phone displays. The high motion tolerance eliminates the need for rescanning barcodes when time is of the essence. As a hallmark of Datalogic scanners, a successful read is accompanied by a loud audible beep and the famous Green Spot technology. From tickets and boarding passes to loyalty cards, the Gryphon 4500 Fixed Series delivers lightning-fast scanning capabilities.

Seamless Connectivity Options

Connecting and setting up the GFS4500 scan module is a breeze. The USB-only version features a standard micro-USB connector with a sturdy locking clip, ensuring a secure connection. For even more versatility, the RS-232 and USB + RS-232 models come with integrated interface cables and support input voltages ranging from 5 to 14 VDC. The RS-232 model offers additional flexibility with software-programmable digital input and output signals, enabling greater integration possibilities. No matter your application or host interface, the GFS4500 scan module is ready to meet your specific requirements.

This product has a 3 year warranty

Specifications

Scan Engine: Area Imager

Light Source

  • Illumination: Red LED 617nm (GFX45XX-RED models)
  • Warm white LED (GFX45XX-WHT models)
  • Aiming: Blue LED’s 470 nm

Scan Pattern: 1280 x 800 Pixels

Scan Rate: 60 full-frame/s

Motion Tolerance: 70 IPS (EAN/UPC)

Image Capture

  • Graphic Formats: BMP, JPEG, TIFF
  • GreyScale: 256, 16, 2, JPEG, TIFF

Capture Area: Field of View: 51° H x 32° V

Contrast Ratio: 15% Minimum reflective difference

Resolution

  • 1D Linear Max. 0.076mm / 3 mils
  • Datamatrix 0.13mm / 5 mils
  • PDF417 0.13 / 5 mils

Depth of field

Minimum distance determined by symbol length and scan angle. Printing resolution, contrast, and ambient light dependent.

Code 39: 5 mil: 4 to 30.0 cm

Code 39: 10 mil: 1.7 to 53.5 cm

Data Matrix: 10 mil: 3.5 to 23.5 cm

Data Matrix: 15 mil: 3.0 to 35.0 cm

EAN/UPC: 13 mil: 4.0 to 82.0 cm

PDF417: 10 mil: 1.5 to 35.0 cm

QR Code: 10 mil: 3.5 to 22.0 cm

Tilt Angle: +/-180°

Pitch Angle: +/- 60°

Skew Angle: +/- 60°

Ambient Light Immunity: 0 - 120,000 Lux

Symbologies supported:

1D:Auto-discriminates all standard 1D codes including GS1 DataBarâ„¢ linear codes

2D:Aztec Code; China Han Xin Code; Data Matrix; MaxiCode; Micro QR Code; QR Code; Dot Code; Dot Matrix

Postal Codes: Australian Post; British Post; China Post; IMB; Japanese Post; KIX Post; Planet Code; Postnet; Royal Mail Code (RM4SCC)

Stacked Codes: EAN/JAN Composites; GS1 DataBar Composites; GS1 DataBar Expanded Stacked; GS1 DataBar Stacked; GS1 DataBar Stacked Omnidirectional; MacroPDF; MicroPDF417; PDF417; UPC A/E Composites

Digital Watermarking: Digimarc Barcodes

Programming Method

Manual: Reads special bar codes

Automatic: Software commands through the RS-232 / USB interfaces

Datalogic Aladdinâ„¢: Windows configuration program

Remote Host Download (Lowers service costs and improves operations)

Driver available: JavaPOS, OPOS Utilities

Indicators/Controls

Scanner Indicators:

Top Front Good Read LED (Adjustable brightness)

Good Read LED "Green spot" on the code

Adjustable Tone & Volume beeper

Communication Type: Corded

Interfaces: GFS4520: USB (micro-USB connector)

Supply Voltage: 5 VDC +/-5%

Power Consumption:

Operating (Typical): < 225 mA Standby/Idle

Automatic Object Sense Mode: 115 mA

Online & Serial OnLine Modes: 55 mA

Drop Specification:

Withstands repeated drops from 1.5m onto concrete surface

Tolerates random vibration, 5 G, from 22 Hz to 300 Hz, 2 hours / 3 axes

Environmental Sealing: IP54

ESD Protection: +/- 16 kV air discharge

Operating Environment: -20° ~ 50°C, Relative Humidity 5 - 95% none condensing

Storage Environment: -40° ~ 70°C, Relative Humidity 5 - 95% none condensing

EMC/Safety Standards:

Complies to EU RoHS & China RoHS

Illuminator Exempt group, Aiming Risk Group 1 according to IEC 62471

External Dimensions (WxDxH): Scanner only : 55 x 48 x 28mm

Weight: 52g
